ARMA MIX EVO+

Slow-running long-shaft agitator for fermenters with dry substrate contents of up to 15%.

Arma Mix EVO+

Our low-speed agitator with a 7.5 kW gear motor at 96 rpm and high energy efficiency thanks to the 3D polyamide agitator blade (Ø 1400 mm).

Advantages of the Arma Mix EVO+

Height adjustment can be made via top link or with hydraulic adjustment of up to ±15°. In addition, the adjustment device is mounted on the sealing plate so that no drilling is required in the tank wall and the installation can also be adapted to other sealing plates.

Thanks to the use of stainless steel inside the tank, reduced speeds at high circulation rates and robust bearings, the durability is particularly high. In addition, the environment is more protected as the pipe does not need to be filled with oil.
The service life of the agitator is extended many times over by an additionally reinforced bearing and a 20 mm thick tube.

Further details

  • Optimal for retrofitting due to small tank openings (800x800mm) without additional core hole drilling
  • Easy and quick replacement and time- and cost-saving maintenance work
  • Approval for Ex zone 2
  • Motor outputs of 7.5 kW
  • pH values 6.5 – 8.5
  • Substrate temperature up to 55°C
  • High swivel range up to +/- 15

Technical data

  • Slow speed motor with 96 rpm
  • 3D polyamide propeller (Ø 1400 mm)
  • Tank opening 800 mm x 800 mm
  • Modular construction
  • Simple assembly, as gas-tight base frame is screwed directly onto the embedding frame in concrete
  • Base plate dimensions optionally at choice

Wir empfehlen Sanftanlaufsteuerung/Frequenzumrichter
Lieferung ohne Anschlusskabel
